Dry Weight (kg)
41.5
Dry Weight (lbs.)
91.5 pounds
Fuel Capacity (gal.)
0.61 US gallons
Fuel Capacity (l)
2.30 litres
Oil Capacity (l)
0.90 litres
Oil Capacity (Quarts)
0.95 US quarts
Bore x Stroke (in,)
1.6 x 1.6 inches
Bore x Stroke (mm)
39.5 x 40.0 mm
Displacement (cc)
49.0 cc
Displacement (ci)
2.99 cubic inches
Engine Type
Single cylinder, two-stroke
Fuel System
Injection
Engine Lubrication
Mixture oil lubrication
Ignition
Seletra 2p D36
Starter
Kick
Wheel Travel - Front (in.)
8.1 inches
Wheel Travel - Front (mm)
205 mm
Wheel Travel - Rear (in.)
7.3 inches
Wheel Travel - Rear (mm)
185 mm
Frame Type
Central-tube frame with double-cradle
Suspension - Front
WP-USD, AER 35, 35 mm
Suspension - Rear
WP shock absorber
Rake
24.0°
